Aquaglide Pavilion Universal Floating Structure

Description

THIS ITEM SHIPS DIRECTLY FROM VENDOR

The Universal Pavilion provides a convenient and comfortable shaded rest area, play area, or social space for up to six users. The rugged Cx3 commercial-grade construction and heavy-duty tent shade are designed to stand up to the elements and it connects to other Aquapark features on all eight sides. Use the Universal Pavilion as a standalone item or incorporate this feature into any Aquaglide Aquapark layout as a universal hub.

Key Tech Features

• Double I-Beam – Extra-reinforced, welded double-I-Beam construction with 3-layer seams.
• Tubular – Welded structural tube construction with 3-layer seams.
• Duratex Cx3 – Premium commercial-grade material optimized for durability, weld strength and UV resistance.
• Interlock 5 – 8 sets of secure and tamper-free 5-ring connections using our 2-Step Vario Strap system.
• Halkey-Roberts valves – With tamper-proof cap for quick, effective inflation/ deflation.
• PRV – Pressure relief valve to help protect against catastrophic over-inflation.

Key User Activities

• Shade – Adds a covered shade feature where users can rest or gather out of the sun.
• Hub – Serves a central hub connection for numerous pathways.

Technical Specifications

• Capacity – 6 Adults / 6 Children
• Max Weight – 1,200 lb. (544 kg) max weight.
• Material – 0.90 mm / 31 oz Cx3
• Minimum Distance from Shore – 10’ (3.0 m)
• Minimum Water Depth – 3.5′
• Minimum Required Total Anchor Weight – 4,400 lb. (2,000 kg)
• Anchor Rings – 4, or 1 with 2-way bridle.
• Accessory Attachment D-rings – 5 each on all 8 sides.
• Dimensions – L 12′ 8″ (385 cm) x W 12′ 8″ (385 cm) x H 12′ 5″ (379 cm)
• Includes – Universal Pavillion and repair kit
• Not Included – Boarding platform, anchor weights, mooring lines, bridles, Vario-Lock straps, and inflation pump
